Air Compressor Introduction
The air compressor adopts a self-developed finishing pump. The integrated production and assembly process ensures that each component is of high quality. The motor is designed with an all-copper movement to ensure 24-hour uninterrupted operation of the whole machine. The anti-corrosion and sterilization coating in the gas tank ensures the cleanliness of the gas source. These high-end air compressors are equipped with a smart screen, which makes it more convenient to view operating data. Optional supporting drying system and sound proof cabinet available.
| Model | DA803 | DA805 | DA807 | DA904 | DA906 | |
|---|---|---|---|---|---|---|
| Voltage frequency | v | 220v/50Hz(110v/60Hz) | 220v/50Hz(110v/60Hz) | 220v/50Hz(110v/60Hz) | 220V/50Hz | 380v/50Hz |
| Power | kW | 1.5 | 2.25 | 3 | 4.4 | 5 |
| Max flow | L/min | 360 | 480 | 720 | 920 | 1000 |
| 0.5MPa exhaust volume | L/min | 156 | 234 | 312 | 480 | 550 |
| Noise | dB(A) | ≤70 | ≤71 | ≤71 | ≤75 | ≤75 |
| Gas tank volume | L | 50 | 70 | 100 | 160 | 200 |
| Machine size | mm | 690*510*750 | 920*510*750 | 1060*550*780 | 1290*550*850 | 1340*580*930 |
| Gross weight | kg | 54/63 | 74/85 | 94/107 | 136/175 | 144/194 |
| Optional dryer | - | Support | Support | Support | Support | Support |
| Optional dental chair | - | 3 to 4 | 5 to 6 | 7 to 8 | 10 to 12 | 12 to 15 |
| Model | DA5001 | DA7001 | DA5002 | DA7002 | DA7003 | DA7004 | |
|---|---|---|---|---|---|---|---|
| Voltage frequency | V | 220v/50Hz, 110V/60Hz | |||||
| Power | kW | 0.55kW | 0.75kW | 1.1kW | 1.5kW | 2.25kW | 3kW |
| Max flow | L/min | 115 | 152 | 230 | 304 | 456 | 608 |
| 0.5MPa | L/min | 60 | 78 | 120 | 156 | 234 | 312 |
| Noise | dB(A) | ≤65 | ≤68 | ≤66 | ≤69 | ≤70 | ≤71 |
| Tank volume | L | 22 | 30 | 50 | 50 | 70 | 100 |
| Gross weight | kg | 23.2/25.4 | 28/33 | 47.4/56.6 | 50/62.5 | 78/90 | 91/114.5 |
