| No. | Component Name | Quantity |
|---|---|---|
| 1 | 24v silence Taiwan DC motor | 1 set |
| 2 | 3-way syringe (cold/hot) | 2 pcs |
| 3 | Water heating system | 1 set |
| 4 | Inductive & manual LED lamp | 1 pc |
| 5 | Saliva ejector (strong and weak) | 1 set |
| 6 | LED film viewer | 1 set |
| 7 | Purified water storage system | 2 sets |
| 8 | Luxury up mounted trolley | 1 set |
| 9 | Rotary ceramic spittoon | 1 set |
| 10 | Double armrest | 1 set |
| 11 | Memory positions | 3 sets |
| 12 | PU cushion | 1 set |
| 13 | 6 in 1 foot pedal | 1 set |
| 14 | Luxury Dentist stool | 1 set |
| 15 | Painting steel base | 1 set |
| 16 | Imported water & air tubes | 1 set |
| 17 | Italy solenoid valve (ODE) | 1 set |
1. Water supply: White PPR Fusion Tube, reserved 4 points copper internal tooth interface.
2. Air supply: White PPR Fusion Tube, reserved 4 points copper internal tooth interface.
3. Drainage: White PVC drain pipe, main pipe 17mm, branch pipe φ50mm.
4. Video/Data: White PVC threading pipe φ 32mm for VGA and USB cables.
5. Negative pressure: Blue UPVC water supply pipe, outer diameter φ50mm (main) / φ32mm (branch).
6. Signal line: White PVC threading tube, 4 points φ20mm sleeve 2*1mm2 line.
7. Power: White PVC threading tube, 4 points φ20mm sleeve 3*1.5mm2 line.
Note: 45-degree joints are required for drainage and pump connections; straight angles are not allowed.
