Product Performance Overview
1. Operating Conditions:
Atmospheric pressure: 70 KPA ~ 106 KPA
Ambient temperature: + 10 °C ~ + 40 °C
Relative humidity: 30% ~ 75%
2. Transport and Storage Conditions:
Ambient temperature range: -20 °C ~ + 50 °C
Relative humidity range: 10% ~ 90%
Atmospheric pressure range: 50 KPA ~ 106 KPA
3. Power Supply:
Battery: 6600mAh / 14.8 V
Charger input voltage: single-phase AC 220V, 50Hz
Charger output voltage: DC 16.8 V
Charging current: 2.5 A
4. Technical Parameters:
4.1 Nominal tube voltage: 60kV (fixed)
4.2 Nominal tube current: 2mA (fixed)
4.3 Nominal power: 120W (60kV 2mA 0.2s) maximum output power
4.4 Operation mode: Intermittent loading, continuous running
4.5 Load time selection range: 0.2 S - 3.2 S
4.6 Operating frequency: 30kHz
4.7 Machine Fuse model: F20AL250V
Charger fuse model: SMT T3.15 AL, 250Vac
